Dynamixel XC430-W240-T

£113.60 £94.67
Metal Gear, Contactless Absolute Encoder, 12V, TTL
SKU
R-902-0147-000

Features

DYNAMIXEL is a robot exclusive smart actuator with fully integrated DC Motor + Reduction Gearhead + Controller + Driver + Network in one DC servo module.

The DYNAMIXEL XC series adopts new features that allow 360 degrees control mode with its contactless magnetic encoder and hollow back case assembly structure. The XL series has the same mechanical structure as the XM430 and XH430 and is compatible with the respective models.

XC430 is a high-performance version of XL430 (Entry-level DYNAMIXEL), that can be applied to robots that require stronger torque. Metal gears are adopted to enhance its durability.

1. Various Operating Modes Velocity Control, Position Control, Extended Position Control, PWM Control 2. Profile Control for Smooth Motion Planning 3. Hollow Back Case Minimizes Cable Stress (3-way-routing) 4. Direct Screw Assembly to the Case (without Nut Insert) 5. Energy Saving with Reduced Current

Package Components

Not included Idler Set (HN11-i101 Set)

Compatible Products

Controller : OpenCM9.04 485 Expansion Board, OpenCR1.0 Interface : USB2Dynamixel, U2D2

Factory Default Settings

ID : 1 Baud Rate : 57600bps (User can change various settings including ID and baud rate according to environment)

Various Cabling Methods

Performance Comparison

Cautions

DYNAMIXEL X-Series cable assembly through hollow case

Organize the entangled cable before assembling the back case.

Do not assemble the back case with entangled cable. The entangled cable can be squashed by the case and cause communication error.

If you use two cables through the hollow case, the cables will be damaged.

Use only one cable through the hollow case.

The DYNAMIXEL X-Series adopted a new gold-plated JST connector for secure and reliable communication.

The connector used for previous Dynamixel is Molex.

To control DYNAMIXEL X-Series actuators via OpenCM or USB2Dynamixel, please use the JST-Molex Convertible Cable enclosed in the package.

However, the Molex-JST convertible cable is NOT included in the XL430 model.

Please purchase a convertible cable when using a controller and interface that supports the JST connector.

Controller Model Controller Connector Cable DynamixelX Connector

Dynamixel C

ommunication

OpenCM+485 Expansion Board Molex (3P, 4P) Robot Cable-X3P 180mm (Convertible) JST-3P TTL
USB2Dynamixel Molex (3P, 4P) Robot Cable-X3P 180mm (Convertible) JST-3P TTL
OpenCR1.0 JST (3P, 4P) Robot Cable-X3P (by length) JST-3P TTL
U2D2 JST (3P, 4P) Robot Cable-X3P (by length) JST-3P TTL
OpenCM+485 Expansion Board Molex (3P, 4P) Robot Cable-X4P 180mm (Convertible) JST-4P RS-485
USB2Dynamixel Molex (3P, 4P) Robot Cable-X4P 180mm (Convertible) JST-4P RS-485
OpenCR1.0 JST (3P, 4P) Robot Cable-X4P (by length) JST-4P RS-485
U2D2 JST (3P, 4P) Robot Cable-X4P (by length) JST-4P RS-485

Specification

Model Name

XC430-W240-T
MCU Robot Cable-X3P 180mm (Convertible)
Input Voltage
Min. [V]

10.0

Recommended [V]

12.0
Max. [V]

14.8
Performance Characteristics
Voltage [V]

12.0
Stall Torque [N·m]

1.90
Stall Current [A]

1.4
No Load Speed [rpm]

70.0
No Load Current [A]

0.06
Continuous Operation

Voltage [V]

-
Torque [N·m]

-
Speed [rpm]

-
Current [A]

-
Resolution

Resolution [deg/pulse]

0.0879
Step [pulse]

4,096
Angle [degree]

360
Position Sensor

Contactless absolute encoder (12Bit, 360 [deg])
Maker : ams(www.ams.com), Part No : AS5601
Operating Temperature

Min. [°C]

-5
Max. [°C]

80
Motor
Coreless
Baud Rate

Min. [bps]

9,600
Max. [bps]

4,500,000
Control Algorithm

PID
Gear Type

Spur
Gear Material

Precious Metal
Case Material

Engineering Plastic
Dimensions (WⅹHⅹD) [mm]

28.5 X 46.5 X 34.0
Dimensions (WⅹHⅹD) [inch]

1.12 X 1.83 X 1.34
Weight [g]

65.00
Weight [oz]

2.29
Gear Ratio

245.2:1
Command Signal

Digital Packet
Protocol Type


Half duplex Asynchronous Serial Communication (8bit, 1stop, No Parity)
Link (Physical)
TTL Level Multi Drop Bus
ID
0 ~ 252
Feedback Position, Velocity, Load, Realtime tick, Trajectory, Temperature, Input Voltage, etc
Protocol version

1.0
2.0(Default
Operating Mode / Angle


Velocity Control mode:Endless turn
Position Control Mode:360 [deg]
Extended Position Control Mode:±256 [rev]
PWM Control Mode:Endless turn
Output [W]

-
Standby Current [mA]

46


  -
